Product advantages: efficient "apple" soil ball,high survival rate, high strength knife shovel, compact structure
1. high efficiency: Three Xian heavy industry tree transplant machine, high working efficiency. It only takes a few tens of
seconds from the start of the shoveling to the digging of the tree. One day of selective digging can dig about 150 trees,
continuous digging can dig about 400 trees when clearing the ground, a tree digging machine is equivalent to 30-100 tree digging workers at the same time.
2. "Apple-shaped" soil ball: The excavated soil ball is like "apple-shaped", and the soil ball is full, which can retain more roots to a greater extent. Improve the survival rate of transplanting seedlings, help reverse seedlings.
3. high survival rate: The tree excavator adopts electromechanical hydraulic integration "static pressure cutting" technology, the cut root section is "level and smooth" thick earth ball, compressive collision resistance. The test showed that there was no obvious structural position change in the soil and root system inside the excavated soil ball, and the survival rate of trees could be significantly improved.
4. High-strength knife and shovel: The knife and shovel of the tree digging machine (including blade) all adopt imported
high-strength wear-resistant alloy plate. After detection, the external force is applied, and the blade is continuously bent
140 degrees, and the continuous operation is performed for 100,000 times.
5. compact structure: the tree digging machine adopts the door frame structure, with internal frame and external frame two kinds of structure. The cutter adopts the upper and lower circular arc structure, from parts to components, matching accuracy in the range of 0.01-0.5mm.
Order(MOQ) :
1 unitPayment :
T/TProduct Origin :
XUZHOU CITY,JIANGSUShipping Port :
QINGDAO PORTLead Time :
5-7DAYSWeight :
1100KG| sx-40 | sx-60 | sx-80 | sx-100 | sx-120 | |
| Soil ball diameter adjustment range | 300-450mm | 500-650mm | 700-850mm | 900-1050mm | 1100-1250mm |
| Top diameter of tree ball A1 | ≦450mm | ≦650mm | ≦850mm | ≦1050mm | ≦1200mm |
| Effective depth of tree ball B | ≥300mm | ≥450mm | ≥550mm | ≥600mm | ≥650mm |
| Tree ball volume | ≥0.05m³ | ≥0.1m³ | ≥0.24m³ | ≥0.32m³ | ≥0.6m³ |
| Head length | ≥1000mm | ≥1200mm | ≥1350mm | ≥1400mm | ≥1600mm |
| Weight of machine head | ≥650kg | ≥850kg | ≥1000kg | ≥1100kg | ≥2000kg |
| Work efficiency | ≥80trees/hour | ≥70trees/hour | ≥70trees/hour | ≥60trees/hour | ≥50trees/hour |
| Adapted excavator (weight) |
≧5 tons | ≧6 tons | ≧7.5 tons | ≧9.5 tons | ≧20 tons |
| Adapted skid machine (power) |
≧50KW | ≧60KW | ≧75KW | ≧75KW | ≧85KW |
| Number of blades |
three | four | four | four | five |
